Why are my Tapcon screws breaking?

The dust can build up and create a situation where the screw is unable to be fully inserted in the hole and if too much torque is applied, the Tapcon® screw may break of shear off.

Why are my Tapcons not grabbing?

The hole needs to be slightly smaller than the diameter of the fastener so that the threads of the Tapcon have something to grab into. If the masonry bit you use is too small you won't be able to drive the Tapcon in at all. If the masonry bit is too large, the Tapcon will not hold.

Do I need to pre drill for Tapcon screws?

Before a Tapcon masonry screw can be installed, a hole must be drilled into the masonry. Use a hammer drill to ensure that the hole has the proper tolerance. The switch on the hammer drill must be in the hammer and rotation mode before starting to drill.

Are Tapcon screws strong?

Stainless Steel Tapcons are reliable, strong, and have outstanding corrosion resistance. These screws are ideal for using to attach fixtures and lumbers to all types of masonry bases, including concrete, brick, and block.

Never Use Tapcons Again!

How much weight can a Tapcon concrete screw hold?

1,360 lbs. *A safety factor of 4:1 or 25% of ultimate pullout/shear value is generally accepted as a safe working load.

Are Tapcon screws better than anchors?

Tapcon and wedge anchors are pre-installed mechanical anchors that attach structural objects to concrete structures. However, the wedge anchor suits heavier-duty applications, vs the Tapcon anchor that typically serve lighter deployments. Another difference between them is in their fastening method.

Why are Tapcon screws blue?

Tapcon+ unmatched performance in concrete, block and brick applications make them an excellent alternative to expansion anchors, plugs, lag shields and have a blue corrosion resistant coating that enables them to withstand the harshest conditions.

Can I use hammer drill with Tapcon screws?

The hole must be drilled using a hammer drill with a carbide tipped bit meeting ANSI standards. A bit that meets ANSI standards will ensure that the hole diameter will meet the requirements of the Tapcon®.

Should I use water when drilling concrete?

Though you don't need to water down the concrete, the water will help to collect and remove the drilling dust, which can be hazardous to your health and "clog" the drill bit. The water can also help to keep your bit from overheating, which in turn helps keep the bit from shattering.

Can you reuse Tapcon holes?

Tapcon Concrete Screws are removable, however it is not recommended to reuse the same hole because the cutting threads can compromise or destroy the holding power. Tapcons are most commonly seen in the Blue Climaseal™ ceramic coating finish.

Why can't I drill through concrete?

Drilling into concrete is difficult because concrete is dense, is hard, and has embedded aggregate stones that can be obstacles to the drill bit. Drilling can quickly dull drill bits. When the bit encounters aggregate, the bit drags even more. The preferred tool for drilling into concrete is a hammer drill.

What diameter Tapcon should I use?

The Tapcon® screw requires the correct diameter of hole to be drilled for the diameter of the Tapcon® screw being installed. The 1/4” requires a 3/16” hole, and the 3/16” requires a 5/32” hole to be drilled into the base material.

What size drill bit do you use for Tapcon screws?

The Tapcon drill bit that is used depends on the diameter of the Tapcon screw being installed. The 3/16” Tapcon requires the use of 5/32” diameter bit, and the 1/4” Tapcon requires a 3/16” diameter bit.

Do concrete screws need a pilot hole?

Unlike self-drilling screws which do not need pilot holes due to their drill bit end, self-tapping screws like concrete screws do require the user to mark a spot for the pilot hole.

Are Tapcon screws good for brick?

The Tapcon concrete screw is suitable for use in a variety of base material, including brick and the mortar joints between the brick.

What's the best screws for concrete?

For that reason, the best concrete screws are either stainless steel, galvanized, or zinc coated. Many are simply coated with a corrosion-resistant layer, which is usually blue. These materials do better in damp conditions and resist the moisture present in concrete surfaces.

Are Tapcons self tapping?

There are many brand names of concrete screws on the market today. The original self-tapping and the most widely recognized one is called Tapcon, which is derived from Tapping Concrete.

Are Tapcon screws rated for outdoor use?

Original Blue Tapcon® Concrete Screw. The Tapcon® concrete screw with the Climaseal® coating gives excellent rust resistance when used for indoor applications and outdoor applications. Tapcons come in two diameters: 3/16” and 1/4”.

How deep should concrete anchors go?

The hole needs to be drilled 1/4" deeper than the anchor will penetrate. The hole can't be drilled while the fixture is in place due to the fact that the hole is larger than the diameter of the bolt being inserted into it.
